Description
The ARKV6X Extended Range Bundle includes an ARK PAB Carrier with a mated ARKV6X Extended Range. The flight controller module is screwed into the carrier using four M2x8mm screws.
ARKV6X Extended Range Bundle
$800.00
Blue Framework Listed, USA built, NDAA compliant ARKV6X Extended Range flight controller (triple IIM-42653 IMUs) mounted on an ARK Pixhawk Autopilot Bus Carrier.
Additional information
| NDAA | yes |
|---|---|
| Made in USA | yes |
| Docs markdown | https://docs.arkelectron.com/products/flight-controller/arkv6x.md |
ARKV6X Extended Range
| Weight | 5 g |
|---|---|
| Dimensions | 3.6 × 2.9 × 0.5 cm |
| Voltage range | 5V |
| Continuous current | 500mA (300mA system, 200mA heater) |
| Protocol | UART |
| Connector | Pixhawk Autopilot Bus |
| Mounting | Pixhawk Autopilot Bus (PAB) |
| Weight | 5 g |
| NDAA | yes |
| Made in USA | yes |
| Firmware | ArduPilot, PX4 |
| Docs markdown | https://docs.arkelectron.com/products/flight-controller/arkv6x.md |
ARK Pixhawk Autopilot Bus Carrier
| Weight | 22 g |
|---|---|
| Dimensions | 7.4 × 4.35 × 1.2 cm |
| Voltage range | 5V |
| Protocol | CAN, Ethernet, I2C, PWM, SPI, UART |
| Mounting | Pixhawk Autopilot Bus (PAB) |
| Weight | 22 g |
| NDAA | yes |
| Made in USA | yes |
| Docs markdown | https://docs.arkelectron.com/products/flight-controller/ark-pixhawk-autopilot-bus-carrier.md |
